EBE 85

The profiles of the thermal break system EBE 85 have a depth of 85 mm and can hold insulating glazing panels of up to 68 mm. The sashes and frames are overlapping on the inside and coplanar externally.EBE 85 is part of the EBE profile series and represents Secco Sistemi’s answer to heat and sound insulation. With the innovative thermal break technology in polyamide and polyurethane, EBE attains strong structural profiles in the relevant sections.

SYSTEM FEATURES

  1. glazing bead
  2. fitting groove for glazing of up to 68 mm thick
  3. fitting groove for hardware
  4. coplanarity on the exterior and overlap on the interior
  5. frame with weep system and triple gasket
  6. structural thermal break in polyamide and polyurethane

elevation

The small profiles placed in front of the glass to fix it are also design elements of the frame and are produced in the same finishes as the frame

squared

thin

gothic

HINGES

To better integrate into the window frame, the hinges are slender, minimal and provided in the same finishes as the frame. In tilt and turn, the hinges can be concealed

two-wing hinge stainless steel corten steel

three-wing hinge stainless steel corten steel

concealed only for doors galvanized steel

HANDLES

Discrete, geometric, minimal and in the same finishes as the frame, the handles integrate perfectly into the frame

vitruvio tronca stainless steel brass

vitruvio quadra stainless steel corten steel

vitruvio tonda stainless steel brass

vitruvio ovale stainless steel brass

MATERIALS

EBE 85 is also available in 4 precious metals in the Bi-material combination, combining two different materials between the interior and the exterior

galvanized steel varnished

stainless steel scotch brite burnished

corten steel oxidized

brass natural burnished
